Product SKUs
|
|
AS -2014S-TR
|
|
Motherboard
|
|
Super H12SSL-i
|
|
Processor
|
|
CPU
|
|
|
Note
|
-
Supports up to 280W TDP CPUs (Air Cooled)
|
|
System Memory
|
|
Memory
|
-
Slot Count: 8 DIMM slots
-
Max Memory (1DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
-
View Memory Options
|
|
Memory Voltage
|
|
|
On-Board Devices
|
|
Network Connectivity
|
-
2 RJ45 1GbE
-
View AOC Options
|
|
IPMI
|
-
Support for Intelligent Platform Management Interface v.2.0
-
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
|
Input / Output
|
|
LAN
|
-
1 RJ45 1 GbE Dedicated BMC LAN port
-
2 RJ45 1 GbE LAN ports
|
|
USB
|
|
|
Video
|
|
|
Serial
|
|
|
System BIOS
|
|
BIOS Type
|
|
|
Management
|
|
Software
|
|
|
Power configurations
|
-
ACPI/APM Power Management
|
|
Security
|
|
Hardware
|
-
Trusted Platform Module (TPM) 2.0
-
Silicon Root of Trust (RoT) – NIST 800-193 Compliant
|
|
Features
|
-
Cryptographically Signed Firmware
-
Secure Boot
-
Secure Firmware Updates
-
Automatic Firmware Recovery
-
System Lockdown
|
|
PC Health Monitoring
|
|
CPU
|
-
4+1 Phase-switching voltage regulator
-
Monitors for CPU Cores, Chipset Voltages, Memory.
|
|
FAN
|
-
Fans with tachometer monitoring
-
Pulse Width Modulated (PWM) fan connectors
-
Status monitor for speed control
|
|
Temperature
|
-
Monitoring for CPU and chassis environment
-
Thermal Control for fan connectors
|
|
Certifications
|
|
Operating Systems
|
|
|
|
|
Chassis
|
|
Form Factor
|
|
|
Model
|
|
|
Dimensions and Weight
|
|
Height
|
|
|
Width
|
|
|
Depth
|
|
|
Package
|
-
11.4" (H) x 26.7" (W) x 34.5" (D)
|
|
Weight
|
-
Gross Weight: 60 lbs (27.2 kg)
-
Net Weight: 33.5 lbs (15.2 kg)
|
|
Available Color
|
|
|
Front Panel
|
|
Buttons
|
-
Power On/Off button
-
Reset button
|
|
LED
|
-
HDD activity LED
-
Information LED
-
Network activity LEDs
-
Power Fail LED
-
Power status LED
|
|
Expansion Slots
|
|
PCI-Express (PCIe) Configuration
|
-
Default
-
5 PCIe 4.0 x16 LP slots
-
2 PCIe 4.0 x8 LP slots
-
View AOC Options
|
|
M.2
|
-
2 M.2 PCIe 4.0 x4 slots (M-key 2242/2260/2280/22110)
|
|
Drive Bays / Storage
|
|
Drive Bays Configuration
|
-
Default: Total 12 bays
-
12 front hot-swap 3.5" SATA drive bays
-
Option A: Total 14 bays
-
12 front hot-swap 3.5" SATA drive bays
-
2 rear hot-swap 2.5" SATA* drive bays
-
(*SATA support may require additional storage controller and/or cables, please see the optional parts list for details)
-
View Drive Options
|
|
System Cooling
|
|
Fans
|
-
Up to 3 x 80x80x38mm middle cooling Fan(s)
|
|
Power Supply
|
|
|
2x 920W Redundant (1 + 1) Platinum Level (94%) power supplies
|
|
Dimension (WxHxL)
|
76 x 40 x 336 mm
|
|
Input
|
920W: 100-127Vac
920W: 200-240Vac
920W: 100-127Vac / 50-60Hz
920W: 200-240Vac / 50-60Hz
920W: 200-240Vdc / 50-60Hz
|
|
+12V
|
Max: 75A / Min: 0A (100Vac-127Vac)
Max: 75A / Min: 0A (200Vac-240Vac)
|
|
5V SB
|
Max: 4A / Min: 0A
|
|
Output Type
|
Backplanes (gold finger)
|
|
Operating Environment
|
|
ROHS
|
|
|
Environmental Spec.
|
-
Operating Temperature: 10°C to 35°C (50°F to 95°F)
-
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
-
Operating Relative Humidity: 8% to 90% (Non-Condensing)
-
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
|
|
For detailed specifications, options, and compatibility, please refer to the latest official Supermicro documentation and the actual quotes/specifications from Autech.
-
Single AMD EPYC™ 7002/7003 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
-
8 DIMMs; up to 2TB 3DS ECC DDR4-3200MHz
RDIMM/LRDIMM
-
5 PCIe 4.0 x16 LP slots + 2 PCIe 4.0 x8 LP slots
-
12 Hot-swap 3.5" SATA3 drive bays,
2 rear Hot-swap 2.5" SATA3 Drive bays via optional kit
M.2 Interface: 2 PCIe 4.0 x4
M.2 Form Factor: 2242, 2260, 2280, 22110
M.2 Key: M-key
- Backup storage
- Web or Database Servers
- Compact Network Appliance
