SuperWorkstation SYS-532AW-C

适用于 3D 设计与内容创作的单路中塔式工作站。

型号 : SYS-532AW-C

数量 :

SYS-532AW-C 是 Supermicro SuperWorkstation 单处理器服务器等级工作站。适用于 3D 设计与内容创作的单路中塔式工作站。

本机型面向需要可靠运算、存储、扩展与专业图形配置的工作站部署。主要配置参考包含 Intel® Core™ Ultra 9/7/5 (Series 2) processors、Mid-Tower、4 default / 6 max 与 1x 1000W。

以下规格依据 Supermicro 官方 SYS-532AW-C 产品頁整理，实际出货配置仍以 AUTECH 报价与原厂最新资料为准。

Product SKUs
SuperWorkstation SYS-532AW-C

Motherboard
Super X14SAE

Processor
CPU	Single LGA-1851 Intel® Core™ Ultra 9/7/5 (Series 2) processors
Core Count	Up to 24C/24T; Up to 36MB Cache
Note	Supports up to 125W TDP CPUs (Air Cooled)

GPU
Max GPU Count	Up to 1 triple-width or 1 double-width GPU
Supported GPU	NVIDIA PCIe: RTX 5000 Ada, RTX 6000 Ada Generation NVIDIA: GeForce RTX 5070, GeForce RTX 5080, GeForce RTX 5090

System Memory
Memory	Slot Count: 4 DIMM slots Max Memory (2DPC): Up to 192GB 5600MT/s ECC/non-ECC DDR5 UDIMM
Memory Voltage	1.1V

On-Board Devices
SATA	SATA (6Gbps) via Intel® W880; RAID 0/1/5/10 support
Chipset	Intel® W880
Network Connectivity	1 RJ45 1GbE with Intel® I219-LM 1 RJ45 2.5GbE with Intel® I226-LM

Input / Output
USB	2 USB 3.2 Gen1 Type-A ports (front) 3 USB 3.2 Gen2 Type-A ports (rear) 1 USB 3.2 Gen2 Type-C port (rear) 1 USB 3.2 Gen2 Type-C port (front) 1 Thunderbolt™ 4 Type-C port (rear)
Video	1 HDMI 2.1 port (rear) 1 DisplayPort 2.1 port (rear)
Audio	7.1 HD Audio
TPM	1 TPM Onboard TPM & TPM Header

System BIOS / Management / Security
BIOS Type	AMI 256MB SPI Flash
Management Software	Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO)
Power Configurations	ACPI 6.0 Power Management
Security Features	Cryptographically Signed Firmware Secure Boot
Security Hardware	Trusted Platform Module (TPM) 2.0

PC Health Monitoring
Voltage	+1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM temperature

Dimensions and Weight
Height	17.72" (450 mm)
Width	8.07" (205 mm)
Depth	18.5" (470 mm)
Package	24.29" (H) x 12.8" (W) x 23.23" (D)
Weight	Gross Weight: 19.2 lbs (8.7 kg) Net Weight: 14.1 lbs (6.4 kg)
Available Color	Black

Front Panel
Buttons	Power On/Off
LED	HDD activity Power status LED
Port	Audio Jack-Combo microphone input / audio output port USB Type-A Ports: USB 3.2 Gen 1x1 ports (5G) USB Type-C: USB 3.2 Gen 2x2 port (20G)

Expansion Slots
PCI-Express (PCIe) Configuration	Default: 2 PCIe 5.0 x8 (in x16) FHFL slots; 1 PCIe 4.0 x4 (in x4) FHHL slot Option A: 1 PCIe 5.0 x16 (in x16) FHFL slot; 1 PCIe 4.0 x4 (in x4) FHHL slot
M.2	1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280 default) 1 M.2 PCIe 4.0 x4 NVMe slot (M-key 22110 default / 2280)

Drive Bays / Storage
Drive Bays Configuration	Default: Total 6 bays 2 internal fixed 3.5"/2.5" SATA drive bays 4 internal fixed 2.5" NVMe/SATA drive bays NVMe support may require additional storage controller and/or cables
M.2	1 M.2 PCIe 4.0 x4 NVMe slot (M-key 22110 default / 2280) 1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280 default)

System Cooling
Fans	Up to 4x 120mm fan(s)

Operating Environment
Environmental Spec.	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
